TAIMES T540
5.4米巨幅重型喷绘机
防撞装置
回流保护
智能羽化
缺墨警报
自动测高
连打功能
负压调节
UV固化
| T540 打印速度参数 | ||||
| 喷头型号 | 高速模式 | 标准模式 | 高画质模式 | 颜色配置 |
| KM1024i-30PL 12 Heads |
480×360 dpi 1 pass 720 m²/h |
480×720 dpi 2 pass 360 m²/h |
480×1,080 dpi 3 pass 240 m²/h |
 |
| KM1024i-30PL 8 Heads |
480×360 dpi 1 pass 480 m²/h |
480×720 dpi 2 pass 260 m²/h |
480×1,080 dpi 3 pass 174 m²/h |
|
| KM1024i-30PL 4 Heads |
540×360 dpi 2 pass 220 m²/h |
540×720 dpi 3 pass 150 m²/h |
240×1,080 dpi 4 pass 120 m²/h |
|
| KM512i-30PL 8 Heads |
480×360 dpi 2 pass 230 m²/h |
480×540 dpi 3 pass 160 m²/h |
480×540 dpi 4 pass 120 m²/h |
|
| T540 技术参数表 | ||||
| 打印控制 | ||||
| 喷墨技术 | Industrial Piezoeiectric Inkjet | |||
| 墨水类型 | 溶剂型油墨 | |||
| RIP软件 | Maintop ( Optional Photoprint/ ONYX ) | |||
| 颜色配置 | C/ M/ Y/ K | |||
| 操作系统 | Win 7/10/11 64 Bits | |||
| 图像格式 | TIF/ JPEG/ EPS/ PDF | |||
| 喷头高度 | 可调高度 2-8mm | |||
| 打印材料 | Leather, Lamp Film, Lamp Cloth, PP Paper, Car sticker, Film, Acid Paper, Copperplate Paper, Oil Painting Cloth, etc | |||
| 介质规格 | Maximum Media Width 5,400mm | |||
| 打印尺寸 | Maximum Print Width 5,300mm | |||
| 最大材料重量 | Optional Independent Take up System | |||
| 干燥系统 | ||||
| UV固化灯 | ||||
| 数据接口 | Hi-Speed USB 3.0 | |||
| 电源要求 | ||||
| 最大功率 | 3.5KW+ 10KW Dryer | |||
| 接入参数 | AC220V (±5%); 50HZ/60HZ | |||
| 运行环境 | ||||
| 湿度 | 35~80% RH (NO Condensing) | |||
| 温度 | 25~32℃; or more Recommended NO Frost | |||
| 规格 | ||||
| 机器尺寸/净重 | L7,600×W1,200×H1,850 mm/ 2,700 KG | |||
| 包装尺寸/毛重 | L7,600×W1,150×H1,850 mm/ 3,200 KG | |||
