TAIMES TR3300SD
全能型3.2米工业UV网带机
防撞装置
回流保护
智能羽化
缺墨警报
自动测高
连打功能
负压调节
UV固化
| TR3300SD打印速度参数 | ||||
| 喷头型号 | KONICA 1024i 6PL （3 ROWS） |
KONICA 1024i 13PL （3 ROWS） |
KONICA 1024A 6PL （3 ROWS） |
颜色配置 |
| 双喷模式 | 50 m²/h | 60 m²/h | 50 m²/h |  |
| Color White Color Mode | 32 m²/h | 38 m²/h | 32 m²/h | |
| 外光全彩模式 | 100 m²/h | 120 m²/h | 100 m²/h | |
| 内光量产模式 | 60 m²/h | 75 m²/h | 60 m²/h | |
| 内光高精模式 | 45 m²/h | 57 m²/h | 45 m²/h | |
| TR3300SD技术参数表 | ||||
| 打印控制 | ||||
| 喷墨技术 | Industrial Piezoeiectric Inkjet | |||
| 墨水类型 | Environmentally Protective UV Ink | |||
| RIP软件 | PrintFactory | |||
| 颜色配置 | 4 Color/ 7 Color ( C/ M/ Y/ K/ Lc/ Lm/ W ) | |||
| 操作系统 | Win 7/ 10/ 11 64 Bits | |||
| 图像格式 | BMP/ TIF/ JPEG/ EPS/ PDF | |||
| 喷头高度 | Maximum Print Thickness 3mm | |||
| 打印材料 | Soft Materials such as Soft Film, Light Strips, Car Stickers, 3P Cloth, Knife Scraping Cloth, Oil Painting Cloth, Light Box Cloth, Super Transparent Stickers, etc | |||
| 介质规格 | Maximum Media Width 3,300mm | |||
| 打印尺寸 | Maximum Print Width 3,200mm | |||
| 最大材料重量 | Roll to Roll, Automatic Receiving and Feeding System | |||
| 干燥系统 | ||||
| UV固化灯 | LG LED-UV Cold Light Curing Lamp | |||
| 数据接口 | Hi-Speed USB 3.0 | |||
| 电源要求 | ||||
| 最大功率 | ＞ 25A; 5.5KW | |||
| 接入参数 | AC220V(±10%); 50HZ/60HZ | |||
| 运行环境 | ||||
| 湿度 | 30~65% RH (NO Condensing) | |||
| 温度 | 20~30℃; or more Recommended NO Frost | |||
| 规格 | ||||
| 机器尺寸/净重 | L5,850×W1,360×H2,000 mm/ 2,800 KG | |||
| 包装尺寸/毛重 | L6,050×W1,600×H2,300 mm/ 3,100 KG | |||
