TAIMES TR5300SD

5.3米巨幅双面喷UV工业卷材机
ANTI COLLISION DEVICE

防撞装置

backflow protection

回流保护

INTELLIGENT FEATHERING

智能羽化

LOW INK ALARM

缺墨警报

AUTOMATIC HEIGHT MEASUREMENT

自动测高

CONTINUOUS PRINTING FUNCTION

连打功能

NEGA TIVE PRESSURE REGULATION

负压调节

UV CURING

UV固化

TR5300SD-英文版网页排版-01-20250415
TF-1810-2
TR5300SD-英文版网页排版-03
TR5300SD
TR5300SD
TR5300SD
Printer TAIMES TR5300SD
颜色配置 C / M / Y / K / LC / LM / W / LK
喷墨技术 工业压电式喷墨技术
喷头型号 KONICA 1024i-13PL KONICA 1024A-6PL
Color Scheme
Three Rows of Four Colors
( Full Color )		 Four Rows of Six Colors
( CMYK / LC / LM )		 Four Rows of Eight Colors
( CMYK / LC/ LM / LK / W )
生产率 2 ROWS 3 ROWS 2 ROWS 3 ROWS 4 ROWS
Duplex Printing 44 m²/h 66 m²/h 37 m²/h 56 m²/h 74 m²/h
Single Spray Exterior Light 88 m²/h 132 m²/h 74 m²/h 111 m²/h 148 m²/h
Single Spray Interior Light 58 m²/h 87 m²/h 48 m²/h 72 m²/h 96 m²/h
Single Spray Interior Light Quality 44 m²/h 66 m²/h 36 m²/h 54 m²/h 72 m²/h
最大打印尺寸 Width: 5,200 mm ( 205 '' )
Print Height 48 mm ( Max Printing Weight: ≤ 100 kg/m² )
介质类型 Any Soft Materials such as Soft Film, Backlit Film, Car Sticker, 3P Cloth, Coated Banner, Canvas, Light Box Cloth, One Way Vision Sticker.
墨水类型 Environmental Friendly UV Curable Ink ( Excluding VOC )
Curing System LG LED-UV冷光源固化系统
RIP软件 Photoprint / Onyx / Printer Factory / Colorgate
图像格式 TIF / JPG / EPS / PDF
电源要求 > 25A, 6.5KW; AC220V ( ±5% ), 50~60HZ
Size / Weight L7,800 × W1,500 × H2,150 mm ( L307 × W59 × H85 '' ) ; Net Weight 4,300 KG ( 9,480 LB )

TR5300SD
